High-Speed PLC Controlled Stranding Machine for Fine Wires
Product Summary: The HT-630P is a compact automatic double twist bunching machine designed for high-speed stranding of fine copper wires. With a 630mm spool diameter and 2400 RPM rotor speed, it delivers efficient production for cable conductors up to 6.0 mm² stranded cross-section. Equipped with PLC and touch screen HMI, it ensures precise pitch control and easy operation.
Key Selling Points
High Rotor Speed – 2400 RPM: Achieves faster bunching cycles, boosting productivity per shift compared to conventional machines.
PLC + Touch Screen HMI: Enables simple parameter setting, real-time monitoring, and automatic fault diagnosis, reducing operator training time.
IP54 Protection Grade: Ensures reliable operation in dusty and humid workshop environments, prolonging service life.
Wide Wire Range – 0.20–1.00 mm: Handles multiple wire gauges for flexible production of cables used in electronics, automotive, and telecom.
Compact Footprint with 15kW Motor: Offers high power density for space-constrained production lines.
Technical Specifications
Parameter
Value
Spool Diameter
Φ630 mm
Single Wire Diameter
0.20–1.00 mm
Stranded Cross-Section
0.5–6.0 mm²
Max Rotor Speed
2400 RPM
Pitch Range
8–40 mm
Control System
PLC + Touch Screen HMI
Protection Grade
IP54
Main Motor Power
15 kW
Models and Options
The HT-630P is a standard model; optional configurations may include different pay-off systems, tension control upgrades, and customized pitch settings. Contact HONTA for further details.
Materials and Structure
Main frame and components are constructed from structural steel/alloy for strength and durability. The bow components utilize carbon-fiber material to reduce weight and minimize inertia at high speeds, enhancing stability and reducing energy consumption.
Applications
Suitable for stranding fine copper wires used in power cables, automotive wiring, communication cables, electronic appliances, and new energy cable assemblies.
Customization
HONTA offers customization of pitch range, tension control, and special pay-off/take-up configurations to meet specific production requirements. Please consult with our engineering team.
FAQ
1. What is the maximum wire diameter the HT-630P can handle?
The machine accepts single wire diameters from 0.20 mm to 1.00 mm.
2. What is the control system used?
It uses a PLC combined with a touch screen HMI for easy parameter setting and monitoring.
3. What is the protection rating?
IP54, which protects against dust ingress and water splashes from any direction.
4. Can it strand aluminum wires?
Yes, within the specified diameter range, it can strand both copper and aluminum wires.
5. What is the typical delivery time?
Delivery time varies based on order volume. Please contact our sales team for accurate lead time.
6. Do you provide installation and training?
Yes, we offer pre-shipment testing and on-site installation and training support.
7. What is the machine weight and dimensions?
Exact weight and dimensions are available upon request. The machine has a compact footprint for its power class.
